Chain Complexes Code

When we looked at the delta complex we got a chain of 'face maps' between each dimension and the next lower one. homology face maps

In homology we treat this as a chain of Abelian groups (more detail on the page here).

For implementation of co-chain see page here.

  chain and cochain

FriCAS Implementation

In our FriCAS Implementation 'ChainComplex' represents, not the faces at each dimension, but the maps between them. Each map is represented by a (not necessarily square) matrix. These matrices may have a width or a height of zero.

Since the chain starts and ends with zero (trivial group) then:

Creating Chain Complexes

Here are two ways to construct a chain complex:

Usually it is easier to construct a simplicial or delta complex first and then call chain function.

Here we construct a simplicial complex then call chain function:

(1) -> b1 := sphereSolid(2)$SimplicialComplexFactory(Integer)

   (1)  points 1..3
          (1,2,3)
                         Type: FiniteSimplicialComplex(Integer)
(2) -> chain(b1)

                  + 1    1    0 + + 1 +
                  |             | |   |
   (2)  [0  0  0],|- 1   0    1 |,|- 1|,[]
                  |             | |   |
                  + 0   - 1  - 1+ + 1 +
                                        Type: ChainComplex
We could alternatively construct from a list of matrices.

Example 1 - Solid 2D circle.

(1) -> )expose DeltaComplex

   DeltaComplex is now explicitly exposed in frame frame1

(1) -> b1 := sphereSolid(2)$SimplicialComplexFactory(Integer)

   (1)  points 1..3
          (1,2,3)
          Type: FiniteSimplicialComplex(Integer)
(2) -> d1 := deltaComplex(b1)

   (2)
                2D:[[1,- 2,3]]
         1D:[[1,- 2],[1,- 3],[2,- 3]]
               0D:[[0],[0],[0]]
                     Type: DeltaComplex(Integer)
(3) -> c1 := chain(d1)

                  + 1    1    0 + + 1 +
   (3)  [0  0  0],|- 1   0    1 |,|- 1|,[]
                  + 0   - 1  - 1+ + 1 +
                              Type: ChainComplex

Example2 - Solid 3D Sphere.

(4) -> b2 := sphereSolid(3)$SimplicialComplexFactory(Integer)

   (4)  points 1..4
         (1,2,3,4)
          Type: FiniteSimplicialComplex(Integer)
(5) -> d2 := deltaComplex(b2)

   (5)
                          3D:[[1,- 2,3,- 4]]
             2D:[[1,- 2,4],[1,- 3,5],[2,- 3,6],[4,- 5,6]]
         1D:[[1,- 2],[1,- 3],[1,- 4],[2,- 3],[2,- 4],[3,- 4]]
                         0D:[[0],[0],[0],[0]]
                     Type: DeltaComplex(Integer)
(6) -> c2 := chain(d2)

   (6)
                                               + 1    1    0    0 +
                + 1    1    1    0    0    0 + |- 1   0    1    0 | + 1 +
                |- 1   0    0    1    1    0 | | 0   - 1  - 1   0 | |- 1|
   [0  0  0  0],|                            |,|                  |,|   |,[]
                | 0   - 1   0   - 1   0    1 | | 1    0    0    1 | | 1 |
                + 0    0   - 1   0   - 1  - 1+ | 0    1    0   - 1| +- 1+
                                               + 0    0    1    1 +
                              Type: ChainComplex

Example 3 - Hollow 2D circle.

(7) -> b3 := sphereSurface(2)$SimplicialComplexFactory(Integer)

   (7)  points 1..3
           (1,2)
          -(1,3)
           (2,3)
          Type: FiniteSimplicialComplex(Integer)
(8) -> d3 := deltaComplex(b3)

   (8)
         1D:[[1,- 2],[- 1,3],[2,- 3]]
               0D:[[0],[0],[0]]
                     Type: DeltaComplex(Integer)
(9) -> c3 := chain(d3)

                  + 1   - 1   0 + ++
   (9)  [0  0  0],|- 1   0    1 |,||
                  + 0    1   - 1+ ++
                              Type: ChainComplex

Example 4 - Hollow 3D Sphere.

(10) -> b4 := sphereSurface(3)$SimplicialComplexFactory(Integer)

   (10)  points 1..4
           (1,2,3)
          -(1,2,4)
           (1,3,4)
          -(2,3,4)
          Type: FiniteSimplicialComplex(Integer)
(11) -> d4 := deltaComplex(b4)

   (11)
            2D:[[1,- 2,4],[- 1,3,- 5],[2,- 3,6],[- 4,5,- 6]]
          1D:[[1,- 2],[1,- 3],[1,- 4],[2,- 3],[2,- 4],[3,- 4]]
                          0D:[[0],[0],[0],[0]]
                     Type: DeltaComplex(Integer)
(12) -> c4 := chain(d4)

                                                     + 1   - 1   0    0 +
                      + 1    1    1    0    0    0 + |- 1   0    1    0 | ++
                      |- 1   0    0    1    1    0 | | 0    1   - 1   0 | ||
   (12)  [0  0  0  0],|                            |,|                  |,||
                      | 0   - 1   0   - 1   0    1 | | 1    0    0   - 1| ||
                      + 0    0   - 1   0   - 1  - 1+ | 0   - 1   0    1 | ++
                                                     + 0    0    1   - 1+
                              Type: ChainComplex

Example 5 - Torus Surface.

(13) -> b5 := torusSurface()$SimplicialComplexFactory(Integer)

   (13)  points 1..7
           (1,2,3)
           (2,3,5)
           (2,4,5)
           (2,4,7)
           (1,2,6)
           (2,6,7)
           (3,4,6)
           (3,5,6)
           (3,4,7)
           (1,3,7)
           (1,4,5)
           (1,4,6)
           (5,6,7)
           (1,5,7)
          Type: FiniteSimplicialComplex(Integer)
(14) -> d5 := deltaComplex(b5)

   (14)
   VCONCAT
      VCONCAT
         VCONCAT
        ,
             2D:
              [[1,- 2,7], [1,- 5,10], [2,- 6,15], [3,- 4,16], [3,- 5,17],
               [4,- 6,20], [7,- 9,13], [8,- 9,16], [8,- 11,18], [10,- 11,21],
               [12,- 14,17], [12,- 15,18], [13,- 14,19], [19,- 20,21]]
     ,
          1D:
           [[1,- 2], [1,- 3], [1,- 4], [1,- 5], [1,- 6], [1,- 7], [2,- 3],
            [2,- 4], [2,- 5], [2,- 6], [2,- 7], [3,- 4], [3,- 5], [3,- 6],
            [3,- 7], [4,- 5], [4,- 6], [4,- 7], [5,- 6], [5,- 7], [6,- 7]]
  ,
       0D:[[0],[0],[0],[0],[0],[0],[0]]
                     Type: DeltaComplex(Integer)
(15) -> c5 := chain(d5)

   (15)
     [0  0  0  0  0  0  0]
  ,
   [[1,1,1,1,1,1,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0],
    [- 1,0,0,0,0,0,1,1,1,1,1,0,0,0,0,0,0,0,0,0,0],
    [0,- 1,0,0,0,0,- 1,0,0,0,0,1,1,1,1,0,0,0,0,0,0],
    [0,0,- 1,0,0,0,0,- 1,0,0,0,- 1,0,0,0,1,1,1,0,0,0],
    [0,0,0,- 1,0,0,0,0,- 1,0,0,0,- 1,0,0,- 1,0,0,1,1,0],
    [0,0,0,0,- 1,0,0,0,0,- 1,0,0,0,- 1,0,0,- 1,0,- 1,0,1],
    [0,0,0,0,0,- 1,0,0,0,0,- 1,0,0,0,- 1,0,0,- 1,0,- 1,- 1]]
  ,
     + 1    1    0    0    0    0    0    0    0    0    0    0    0    0 +
     |- 1   0    1    0    0    0    0    0    0    0    0    0    0    0 |
     | 0    0    0    1    1    0    0    0    0    0    0    0    0    0 |
     | 0    0    0   - 1   0    1    0    0    0    0    0    0    0    0 |
     |                                                                    | ++
     | 0   - 1   0    0   - 1   0    0    0    0    0    0    0    0    0 | ||
     | 0    0   - 1   0    0   - 1   0    0    0    0    0    0    0    0 | ||
     | 1    0    0    0    0    0    1    0    0    0    0    0    0    0 | ||
     | 0    0    0    0    0    0    0    1    1    0    0    0    0    0 | ||
     | 0    0    0    0    0    0   - 1  - 1   0    0    0    0    0    0 | ||
     | 0    1    0    0    0    0    0    0    0    1    0    0    0    0 | ||
     | 0    0    0    0    0    0    0    0   - 1  - 1   0    0    0    0 |,||
     | 0    0    0    0    0    0    0    0    0    0    1    1    0    0 | ||
     | 0    0    0    0    0    0    1    0    0    0    0    0    1    0 | ||
     | 0    0    0    0    0    0    0    0    0    0   - 1   0   - 1   0 | ||
     | 0    0    1    0    0    0    0    0    0    0    0   - 1   0    0 | ||
     | 0    0    0    1    0    0    0    1    0    0    0    0    0    0 | ||
     | 0    0    0    0    1    0    0    0    0    0    1    0    0    0 | ||
     |                                                                    | ++
     | 0    0    0    0    0    0    0    0    1    0    0    1    0    0 |
     | 0    0    0    0    0    0    0    0    0    0    0    0    1    1 |
     | 0    0    0    0    0    1    0    0    0    0    0    0    0   - 1|
     + 0    0    0    0    0    0    0    0    0    1    0    0    0    1 +
                              Type: ChainComplex

Example 6 - Projective Plane.

(16) -> b6 := projectiveSpace(2)$SimplicialComplexFactory(Integer)

   (16)  points 1..6
           (1,2,3)
           (1,3,4)
           (1,2,6)
           (1,5,6)
           (1,4,5)
           (2,3,5)
           (2,4,5)
           (2,4,6)
           (3,4,6)
           (3,5,6)
          Type: FiniteSimplicialComplex(Integer)
(17) -> d6 := deltaComplex(b6)

   (17)
   VCONCAT
      VCONCAT
         VCONCAT
        ,
             2D:
              [[1,- 2,6], [1,- 5,9], [2,- 3,10], [3,- 4,13], [4,- 5,15],
               [6,- 8,11], [7,- 8,13], [7,- 9,14], [10,- 12,14], [11,- 12,15]]
     ,
          1D:
           [[1,- 2], [1,- 3], [1,- 4], [1,- 5], [1,- 6], [2,- 3], [2,- 4],
            [2,- 5], [2,- 6], [3,- 4], [3,- 5], [3,- 6], [4,- 5], [4,- 6],
            [5,- 6]]
  ,
       0D:[[0],[0],[0],[0],[0],[0]]
                     Type: DeltaComplex(Integer)
(18) -> c6 := chain(d6)

   (18)
     [0  0  0  0  0  0]
  ,
     + 1    1    1    1    1    0    0    0    0    0    0    0    0    0    0 +
     |- 1   0    0    0    0    1    1    1    1    0    0    0    0    0    0 |
     | 0   - 1   0    0    0   - 1   0    0    0    1    1    1    0    0    0 |
     | 0    0   - 1   0    0    0   - 1   0    0   - 1   0    0    1    1    0 |
     | 0    0    0   - 1   0    0    0   - 1   0    0   - 1   0   - 1   0    1 |
     + 0    0    0    0   - 1   0    0    0   - 1   0    0   - 1   0   - 1  - 1+
  ,
     + 1    1    0    0    0    0    0    0    0    0 +
     |- 1   0    1    0    0    0    0    0    0    0 |
     | 0    0   - 1   1    0    0    0    0    0    0 |
     |                                                | ++
     | 0    0    0   - 1   1    0    0    0    0    0 | ||
     | 0   - 1   0    0   - 1   0    0    0    0    0 | ||
     | 1    0    0    0    0    1    0    0    0    0 | ||
     | 0    0    0    0    0    0    1    1    0    0 | ||
     | 0    0    0    0    0   - 1  - 1   0    0    0 |,||
     | 0    1    0    0    0    0    0   - 1   0    0 | ||
     | 0    0    1    0    0    0    0    0    1    0 | ||
     | 0    0    0    0    0    1    0    0    0    1 | ||
     | 0    0    0    0    0    0    0    0   - 1  - 1| ||
     |                                                | ++
     | 0    0    0    1    0    0    1    0    0    0 |
     | 0    0    0    0    0    0    0    1    1    0 |
     + 0    0    0    0    1    0    0    0    0    1 +
                              Type: ChainComplex

Example 7 - Klein Bottle.

(19) -> b7 := kleinBottle()$SimplicialComplexFactory(Integer)

   (19)  points 1..8
           (3,4,8)
           (2,3,4)
           (2,4,6)
           (2,6,8)
           (2,5,8)
           (3,5,7)
           (2,3,7)
           (1,2,7)
           (1,2,5)
           (1,3,5)
           (4,5,8)
           (4,5,7)
           (4,6,7)
           (1,6,7)
           (1,3,6)
           (3,6,8)
          Type: FiniteSimplicialComplex(Integer)
(20) -> d7 := deltaComplex(b7)

   (20)
   VCONCAT
      VCONCAT
         VCONCAT
        ,
             2D:
              [[1,- 3,8], [1,- 5,10], [2,- 3,13], [2,- 4,14], [4,- 5,23],
               [6,- 7,12], [6,- 10,15], [7,- 9,18], [8,- 11,22], [9,- 11,24],
               [12,- 16,20], [13,- 15,21], [14,- 16,24], [17,- 19,21],
               [17,- 20,22], [18,- 19,23]]
     ,
          1D:
           [[1,- 2], [1,- 3], [1,- 5], [1,- 6], [1,- 7], [2,- 3], [2,- 4],
            [2,- 5], [2,- 6], [2,- 7], [2,- 8], [3,- 4], [3,- 5], [3,- 6],
            [3,- 7], [3,- 8], [4,- 5], [4,- 6], [4,- 7], [4,- 8], [5,- 7],
            [5,- 8], [6,- 7], [6,- 8]]
  ,
       0D:[[0],[0],[0],[0],[0],[0],[0],[0]]
                     Type: DeltaComplex(Integer)
(21) -> c7 := chain(d7)

   (21)
     [0  0  0  0  0  0  0  0]
  ,
   [[1,1,1,1,1,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0,0],
    [- 1,0,0,0,0,1,1,1,1,1,1,0,0,0,0,0,0,0,0,0,0,0,0,0],
    [0,- 1,0,0,0,- 1,0,0,0,0,0,1,1,1,1,1,0,0,0,0,0,0,0,0],
    [0,0,0,0,0,0,- 1,0,0,0,0,- 1,0,0,0,0,1,1,1,1,0,0,0,0],
    [0,0,- 1,0,0,0,0,- 1,0,0,0,0,- 1,0,0,0,- 1,0,0,0,1,1,0,0],
    [0,0,0,- 1,0,0,0,0,- 1,0,0,0,0,- 1,0,0,0,- 1,0,0,0,0,1,1],
    [0,0,0,0,- 1,0,0,0,0,- 1,0,0,0,0,- 1,0,0,0,- 1,0,- 1,0,- 1,0],
    [0,0,0,0,0,0,0,0,0,0,- 1,0,0,0,0,- 1,0,0,0,- 1,0,- 1,0,- 1]]
  ,
   [[1,1,0,0,0,0,0,0,0,0,0,0,0,0,0,0], [0,0,1,1,0,0,0,0,0,0,0,0,0,0,0,0],
    [- 1,0,- 1,0,0,0,0,0,0,0,0,0,0,0,0,0], [0,0,0,- 1,1,0,0,0,0,0,0,0,0,0,0,0],
    [0,- 1,0,0,- 1,0,0,0,0,0,0,0,0,0,0,0], [0,0,0,0,0,1,1,0,0,0,0,0,0,0,0,0],
    [0,0,0,0,0,- 1,0,1,0,0,0,0,0,0,0,0], [1,0,0,0,0,0,0,0,1,0,0,0,0,0,0,0],
    [0,0,0,0,0,0,0,- 1,0,1,0,0,0,0,0,0], [0,1,0,0,0,0,- 1,0,0,0,0,0,0,0,0,0],
    [0,0,0,0,0,0,0,0,- 1,- 1,0,0,0,0,0,0], [0,0,0,0,0,1,0,0,0,0,1,0,0,0,0,0],
    [0,0,1,0,0,0,0,0,0,0,0,1,0,0,0,0], [0,0,0,1,0,0,0,0,0,0,0,0,1,0,0,0],
    [0,0,0,0,0,0,1,0,0,0,0,- 1,0,0,0,0], [0,0,0,0,0,0,0,0,0,0,- 1,0,- 1,0,0,0],
    [0,0,0,0,0,0,0,0,0,0,0,0,0,1,1,0], [0,0,0,0,0,0,0,1,0,0,0,0,0,0,0,1],
    [0,0,0,0,0,0,0,0,0,0,0,0,0,- 1,0,- 1], [0,0,0,0,0,0,0,0,0,0,1,0,0,0,- 1,0],
    [0,0,0,0,0,0,0,0,0,0,0,1,0,1,0,0], [0,0,0,0,0,0,0,0,1,0,0,0,0,0,1,0],
    [0,0,0,0,1,0,0,0,0,0,0,0,0,0,0,1], [0,0,0,0,0,0,0,0,0,1,0,0,1,0,0,0]]
  ,
     ++
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ||
     ++
                              Type: ChainComplex

Next

To go on to implementation of co-chain see page here.
